Windpin Locations

BEFORE

Left Side Vertical Member - Wind Pin

LEFT SIDE
of Vertical Member

Existing Ratchet

Lift Strap

Strap Lift Drum
on left side of
vertical member

Vertical Member

Existing Wind
Pin Bracket

Existing Wind Pin

BEFORE

Right Side Vertical Member - Wind Pin

RIGHT SIDE
of Vertical Member

Existing Ratchet

Lift Strap

Strap Lift Drum
on right side of
vertical member

Vertical Member

Existing Wind
Pin Bracket

Existing Wind Pin


AFTER

Left Side Vertical Member - Wind Pin Retro-Fitted

LEFT SIDE
of Vertical Member

New Double Ratchet
Left Assembly

Wind Pin Strap

Lift Strap

Vertical Member

New Wind Pin Bracket
mounted on
left side of vertical member

Retro-Fitted Wind Pin

AFTER

Right Side Vertical Member - Wind Pin Retro-Fitted

RIGHT SIDE
of Vertical Member

New Double Ratchet Left Assembly

Wind Pin Strap

Lift Strap

Vertical Member

New Wind Pin Bracket mounted on right side of vertical member

Retro-Fitted Wind Pin
